Bow Shackle 8.0mm 0.75T Galvanised Steel TRADE PACKS

Description

Bow Shackle 8.0mm 0.75T are Rated Galvanised Steel fittings. They are also described as Anchor Shackles. This fitting provides a method for anchoring chain and wire rope to some sort of device or anchor point. The round open body providing a rustic or industrial appearance for that timeless look. The advantage of a Bow Shackle over a Dee Shackle is that they allow a much largerer range of motion without binding. The screw pin at one end securely closes the fitting. These fasteners extremely secure once installed. Additionally, the screw pin allows easy removal and movement. Finally, these hackles combine with other fittings, including eye bolts, eye nuts, chain and slings. The recommended WLL is 0.75T using a 6x safety factor for Tensile Strength (MBS) = ~4500kg

Usage: The Bow Shackle 8.0mm 0.75T are Rated Galvanised Steel exist in a range of sizes. All shackles made from hot dipped galvanised steel offer excellent corrosion resistance and durability. Additionally, the core material is high quality high carbon steel. The hot dipped galvanised finish is superior and durable. Low Cost Wire Galvanised Steel Bow Shackles suit general rigging and shade sail applications. Their form accommodates most types of metric threaded rod and bolts. Note that these fittings are STAMPED with a rating for lifting purposes..

Quality: All Low Cost Wire products meet our strict ISO Quality Standards. Firstly, our products achieve the optimal balance between high tensile strength, fatigue resistance, abrasion resistance, and structural stability. Secondly, our long experience in the industry enables the design and manufacture of aesthetically beautiful and functional products. Finally, our products have a special treatment for bright and smooth surface of wire and cable to deliver a truly top-shelf, long lasting product that will look new for ages…

Dimensions: b1 = ~13.0mm b2 = ~21.0mm d = ~8.0mm d2 = ~10.0mm d3 = ~21.0mm h1 = ~31.0mm
