Swage Fork 6.0mm G316 Stainless Steel TRADE PACKS
A Swage Fork 6.0mm terminates 6.0mm Wire Rope. Alternatively, a Swage Fork may be called a Fork Terminal. It has a removable pin secured with a G Clip.
CLICK HERE for single fittings and other sizes
Potentially Very Useful Related Items…
Description
A Swage Fork 6.0mm terminates 6.0mm Wire Rope. Alternatively, a Swage Fork may be called a Fork Terminal. It has a removable pin secured with a G Clip. The non-adjustable G316 Stainless Steel swaged end terminal fastens to anchor points. As a result, swaged Terminals must match the size of the anchor points. Additionally, a Swage Fork Terminals fit a single wire diameter. Other adjustable fittings – normally of a similar swaging style – are used in concert with Swage Fork Terminals. Usually, the pin diameter and the suitable wire size are part of the naming convention.
Usage: The Swage Fork 6.0mm fastens with the removable pin to an anchor hole. An anchor holes form the frame or area that will contain the wire. To clarify, swaging is the process of uniformly crushing a fitting from a starting diameter to a finished diameter. Therefore, the chosen swaging tool must achieve a cold pressure weld. Logically, the requisite pressure and tool size varies with the size of the wire and the fitting. Consequently, we recommend Swaging G316 Stainless Steel fittings onto wire larger than 2.0mm with an adequate hydraulic swaging tool.
Quality: All Low Cost Wire products meet our strict ISO Quality Standards. Firstly, our products achieve the optimal balance between high tensile strength, fatigue resistance, abrasion resistance, and structural stability. Secondly, our long experience in the industry enables the design and manufacture of aesthetically beautiful and functional products. Finally, our products have a special treatment for bright and smooth surface of wire and cable to deliver a truly top-shelf, long lasting product that will look new for ages…
Dimensions: D = ~ 5.5mm; D1 = ~ 4.8mm; L = ~ 58.7mm; L1 = ~ 7.7mm
