Wire Rope Grip 10.0mm G316 Stainless Steel TRADE PACKS

Description

Wire Rope Grips 10.0mm 316 Stainless Steel Large Nut are the fitting that is used to fasten the ends of wire back onto itself. These are ‘swageless’ wire fittings that are also known as bulldog clips or wire clamps. They can be fastened by using a wrench and do not require hydraulic or manual hand swaging. They are best used when using hand swages is not appropriate. These fittings are designed to work with High and Medium Flexibility Stainless Steel Wire Rope. Each size is designed to work with a specific size of wire. The Wire Rope Grip 10.0mm is designed for 9.0mm, and 10.0mm Wire Rope. These Grips are strong… but N/R

Usage: Wire Rope Grips 10.0mm 316 Stainless Steel are best used when using hand swages are not appropriate AND a particular load rating is NOT required. These fittings are designed to work with High and Medium Flexibility Stainless Steel Wire Rope. The fittings can be used in combination with rope and a thimble to make a secure wire loop. Please plan on using 2 grips to secure each loop for ‘small diameter wire’ (<3.0mm) and 3 grips for all larger diameter wire loops.

Note: Over tensioning must be avoided when tightening to prevent stripping the nuts or shearing the thread.

Quality: All Low Cost Wire products meet our strict ISO Quality Standards. Firstly, our products achieve the optimal balance between high tensile strength, fatigue resistance, abrasion resistance, and structural stability. Secondly, our long experience in the industry enables the design and manufacture of aesthetically beautiful and functional products. Finally, our products have a special treatment for bright and smooth surface of wire and cable to deliver a truly top-shelf, long lasting product that will look new for ages…

Dimensions: A = ~x.xmm B = ~x.xmm C = ~x.xmm D = ~x.xmm E = ~x.xmm F = ~x.xmm G = ~x.xmm H = ~x.xmm
