Wire Rope Thimbles G316 Stainless Steel ALL SIZES

$0.29$1.06 Inc GST

Clear
SKU: 1313 Category:

Product Description

Wire Rope Thimbles are the reinforcement that provides structure to the end loop of a stainless steel wire (or rope) run so that when it is secured, the force of the bearing point is evenly distributed along the length of the thimble and minimizes wear and stretch on the wire cable. A Thimble works with hydraulically and mechanically pressed ferrules. Our Wire Rope thimbles are AISI 316 grade stainless steel.

* * * *

Usage: The Wire Rope Thimble G316 Stainless Steel does not terminate wire. Normally, the end of a length of wire is threaded through one side of a swage, the wire is then looped around a thimble and the end of the wire is threaded back through the swage. The swage and thimble are then secured
using a manual crimping tool.  The thimble forms the ‘loop’ secured by the ferrule.  The saddle already secured to the posts or uprights fastens to the loop. A larger thimble can be used with a small diameter wire to afford protection or form a larger loop. And this works if there is clearance.

* * * *

Quality: All Low Cost Wire products meet our strict ISO Quality Standards. As well, they are all made with AISI Marine Grade stainless steel. Firstly, our products achieve the optimal balance between high tensile strength, fatigue resistance, abrasion resistance, and structural stability. Secondly, that long experience with design and manufacturing enables the specification and production of aesthetically beautiful and functional products. Finally, our products have a special electro polished treatment for bright and smooth surface of wire and cable to deliver a truly top-shelf, long lasting product that will look new for ages…

****

Wire Rope Thimble Trade Pack sizing is also available for volume discount transactions

Application

Normally, the end of a length of wire is threaded through one side of a swage, the wire is then looped around a thimble and the end of the wire is threaded back through the swage. The swage and thimble are then secured
using a manual crimping tool. The thimble forms the 'loop' that is normally fastened to the saddle already secured to the posts or uprights that form the frame or area that will contain the wire.

Dimensions are:

In the table below - size indicates the swage size and suits indicates the suitable range of wire diameters



Size Suits A B C D E
1.0mm 0.5mm-1.8mm ~6.9mm ~15.0mm ~17.6mm ~3.6mm ~2.3mm
2.0mm 1.9mm-2.3mm ~10.2mm ~19.9mm ~22.4mm ~5.0mm ~3.8mm
3.0mm 2.4mm-3.5mm ~11.2mm ~20.6mm ~24.3mm ~6.3mm ~4.1mm
4.0mm 3.7mm-4.5mm ~12.8mm ~24.4mm ~28.4mm ~7.7mm ~5.2mm
5.0mm 4.8mm-5.5mm ~15mm ~32.0mm ~37.0mm ~8.0mm ~6.2mm
6.0mm 5.8mm-6.8mm ~17mm ~33.5mm ~39.5mm ~9.0.mm ~7.2mm
7.0mm 6.0mm-7.5mm ~19.0mm ~37.5mm ~44.0mm ~10.0.mm ~8.2mm
8.0mm 6.9mm-8.5mm ~22.0mm ~40.5mm ~48.0mm ~11.0.mm ~9.2mm
10.0mm 8.6mm-11.0mm ~25.0mm ~49.5mm ~59.0mm ~13.2.mm ~11.2mm
12.0mm 11.1mm-13.0mm ~29.0mm ~54.5mm ~66.0mm ~15.2mm ~13.2mm
14.0mm 13.1mm-15mm ~34.0mm ~60.5mm ~74.0mm ~17.2mm ~15.2mm
16.0mm 15.1mm-16mm ~37.5mm ~67.5mm ~83.0mm ~19.2mm ~17.2mm

Specifications

Size

1.0mm, 1.2mm, 1.5mm, 1.6mm, 1.8mm, 2.0mm, 2.4mm, 2.5mm, 3.0mm, 3.2mm, 4.0mm, 4.8mm, 5.0mm, 6.0mm, 6.4mm, 8.0mm, 10.0mm

Pack Size

Single

Wire Diameter

0.5mm, 0.6mm, 0.8mm, 1.0mm, 1.2mm, 1.4mm, 1.5mm, 1.6mm, 1.8mm, 2.0mm, 2.4mm, 2.5mm, 3.0mm, 3.2mm, 4.0mm, 4.8mm, 5.0mm, 6.0mm, 6.4mm, 8.0mm, 10.0mm

Material

Stainless Steel

Grade

AISI G316 (Marine)

Connection Style

Hydraulic Swaging, Manual Swaging, Mechanical/Swageless
