Light Duty Stainless Hand Swaging Tool Range 0.1mm-1.6mm

$39.47 $34.98 Inc GST

Sale!

Light Duty Stainless Hand Swaging Tool Range 0.1mm-1.6mm

$39.47 $34.98 Inc GST

The Light Duty Hand Swager has an “included” cutting ability. ? It is also known as a Mechanical Swage Tool. This tool has a range of sizes of ferrules that they will compress or crimp or swage. They are all excellent manual swage and cutting tools that can be used on copper or aluminium ferrules / swages for 0.1mm to 1.6mm wire rope.

Out of stock: "‘+ HS260 4 Hole Portable Range 0.1mm – 1.5mm" doesn't have sufficient quantity in stock.

SKU: 1430 Categories: ,

Product Description

The Light Duty Stainless Hand Swaging Tool is a 260mm 4 Hole Swaging Tool. It includes a cutting ability. This tool will compress or crimp or swage a range of sizes of ferrules. This tool is available in either Stainless Steel or forged steel construction. Its designed with 4 crimping holes to meet your different needs – all made from hardened stainless steel. The jaws are suitable for both aluminium, copper, and brass sleeves. The 4 Holes (crimping positions) suit swages/ferrules for 0.1mm, 0.5mm, 0.6mm, 0.8mm, 1.0mm, 1.2mm, 1.5mm  and 1.6mm wire rope. This tool is available in either Stainless Steel or forged steel construction

****

Features:  The Light Duty Stainless Hand Swaging Tool is portable.  Conveniently, this tool is stainless and highly corrosion resistant. The smooth one Handed operation does not require any additional Vibration damping Rubber Grips.  Additionally, the tool has forged jaws and a 2 Side Cutters. The two convenient side cutters work on wire up to 2.0mm Galvanised or Stainless Steel Wire Rope. Finally, the Swaging tool has  precision ground Factory formed Swaging Holes for consistent perfect swaging every single time!

****

Usage: The Light Duty Stainless Hand Swaging Tool is recommended for Nickel Coated Copper or Aluminium Hourglass Ferrules or Swages.   The tool suits swaging 0.1mm, 0.5mm, 0.6mm, 0.8mm, 1.0mm, 1.2mm, 1.5mm  and 1.6mm wire rope.

****

Quality:  All Low Cost Wire products meet our strict ISO Quality Standards.  Firstly, our products achieve the optimal balance between component strength, fatigue resistance, abrasion resistance, and structural stability. Secondly, our long experience with wire rope projects enables the design, development  and manufacture of aesthetically beautiful and functional products. Finally, our products have a special treatment for bright and smooth surface of wire and cable to deliver a truly top-shelf, long lasting product that will look new for ages…

Specifications

Model

HS-10SS

Length

260mm

Power Source

Manual

Connection Style

Manual Swaging

Wire Diameter

0.5mm, 0.6mm, 0.8mm, 1.0mm, 1.2mm, 1.5mm, 1.6mm

Material

Stainless Steel

Dimensions

Hole 1 – suits wire ~0.1mm to 0.5mm (or Imperial x.xx)
Hole 2 – suits wire ~0.5mm to 1.0mm (or Imperial X/XX)
Hole 3 – suits wire ~1.0mm to 1.5mm (or Imperial x/xx)
Hole 5 – suits wire ~1.5mm to 2.2mm (or Imperial x/xx)
